Inverex Aerox III 3.2kW Off-Grid UPS Solar Inverter

FOR CONTACT WHATSAPP NO: +92 339 0081624

• 1^st time in Pakistan with Grid-Tie and Self-Consumption Feature
• Upgraded Smart and intelligent solar inverter
• Efficiently work without battery
• Upgraded MPPT based solar charge controller up to 4000watts
• Integrated Bluetooth Interface with Android App
• Battery Equalization
• Data Loggin and Storage function
• Energy Prioritization according to the timer
• Conformal Coating to Prevent from Dust and humidity
• Compatible with (Li-ion, LifePo4 and etc.) batteries with BMS


  Inverex Aerox III 3.2kW Off-Grid Solar Inverter

  Capacity	3200w
  Voltage	230 VC
  Selectable Voltage Range	170-280 VAC
  Frequency range	50hz / 60hz
  AC Voltage regulation	230VAC +5%
  Efficiency (Peak)	90% ~ 93%
  Transfer Time	10ms (For PC) : 20ms (For Home Appliance)
  Waveform	Pure Sine Wave
  Battery Voltage	24 VDC
  Floating Charge Voltage	27 VDC
  Overcharge Protection	31 VDC
  Solar Charger Type	MPPT
  MAX PV Array Open Circuit Volt	500 VDC
  MPP range @ Operating Volt	120 ~ 450 VDC
  Max Solar Charge Current	80A
  Max AC Charge Current	80A
  Dimension	115 x 300 x 400
  Net Wight	8.9 Kg
  Communication interface	USB/RS232
